Oil Gas Water Drilling Replaceable Single Roller Cone Tci Tricone Cutter for Roller Cone Bits

Oil gas water drilling replaceable single roller cone tci tricone cutter for roller cone bits

Product Description

Product  Descriptiopn

1)Cutting Structure
The reamer mainly consists of four or more cones. Cutting Structure with premium tungsten carbide hardfacing or premium tungsten carbide insert of formulas and new techniques is utilized, and increases wear-resistance capability of reamer. The pilot is three cone bit( tricone bit ).

2)Seal and Lubrication
High performance O-ring for bearing seal and advanced grease for lubrication.

3)Product Application
It is suitable for the large size well, mining and infrastructure applications.
4)Main Availability, ( Bit sizes and cone types can be customized as you special order)



Bit Size(single roller)		Bit Type
In.	mm
5 7/8	149.2	517, 537, 617,637,737
6	152.4	517, 537, 617,637,737
8 1/2	215.9	517, 537, 617,637,737
9 7/8	250.8	517, 537, 617,637,737
10 5/8	269.9	517, 537, 617,637,737
12 1/4	311.1	517, 537, 617,637,737
14 3/4”	374.6	517,537,617,637,737
17 1/2”	444.5	517,537,617,637,737

Product Pictures

        Single cone bit is a bit slow, that cone drill bit of speed than the speed of smaller, mainly chaotic cutting rock, suitable for high-speed, high pressure drilling wells sidetracking the old, old wells deepened so slim hole drilling. 1. Applications more widely applicable not only to lateral drilling, and can be used in deep wells.
2. Working torque than the PDC drill bit in the same conditions of pressure and lower strata can reduce the problem of small size drill expansion button to avoid mine accidents.
3. Single cone bit with both three-cone bit and PDC bit of advantage, there is a difference between the two Surrounded by a shortage of more than three-cone bit more suitable for large plastic formation, but also can be applied to PDC bit difficult to deal with hard interlayer, and other complex formations.
4. With the downhole drill motor to achieve high speed and special drilling needs.
5. Size: various sizes 5 7/8”-17 1/2”

5) TCI cone bit
1. Covers almost all IADC codes.
2. Rapid delivery time
3. Meet with API Spec7-1 Standard



6)Please specify the following on enquiry,
1.Bit diameter
2.Drilling formation
3.guide bit/pilot bit diameter
4.cutters type
5.Thread Connection

Packaging & Shipping



Company Information

        Hebei Ranking Bit Manufacture Co.,Ltd is mainly engaged in the development of various series of bits,development,production and sales.

        Ranking company has developed and mass-produced products 3 inches to 26 inches series tci tricone bit,steel tooth tricone bit,various types of PDC bits,cone bit and production and processing assembly 0.6m to 3m large diameter hole opener,pdc hole opener,tci hole opener,steel tooth hole opener.Widely used in the oil,natural gas,hydrology,address,ore drilling engineering,product marketing the country and 20 countries and regions in the world.                  Ranking various rock bits,to ensure full compliance with all the terms and standard of American Petroleum Institute API specification,design,manufacturing and production and to ensure full compliance with the API specification requirements and content.
