Water Well or Oil Well PDC Diamond Drill Bits

Product Description



12 1/4" pdc bit Basical Parameter
Bit Size	12 1/4"
Number of Blade	5
Primary Cutter Size	19MM
Nozzle Qty/Type	7
Gauge Length	2.5"~3.5"
Connection	6 5/8 REG PIN
Operating Parameter
Rotary Speed(r/min)	60~250
Weight on Bit(KN)	30~150
Flow Rate(lps)	40~55

PDC DRILL BITS - STANDARD CONNECTION SIZES
BIT SIZE(INCH)	API REGULAR PIN(INCH)	RECOMMENDED MAKE UP TORQUE(KN.M)
4 1/2 to 4 3/4	2 7/8 API	6.0~7.5
5 1/8 to 7 3/8	3 1/8 API	9.5~12
7 1/2 to 9 3/8	4 1/2 API	16.0~22
9 1/2 to 14 1/2	6 5/8 API	38~43
14 5/8 to 17 1/2	7 5/8 API	46~54
→View More



Click here to view detail parameter for PDC bit.

Contact us representative for additional details about our complete line of new PDC bit product offerings.

Product Pictures

        PDC BITS  are equipped with Hardened Alloy Steel base material;High performance PDC-Cutters;Carbide and Diamond gauge protection;Carbide/Diamond Shock Studs;Threaded or Plain Carbide Nozzles for Flushing.Above features are subject to changes and modifications according to customers' requirements.

        The Diamond PDC bit designed to run at high penetration rates even in applications that call for higher blade and cutter counts. Its unique cutting structure layout adds another dimension to bit stability and smooth running by combining the penetration rate potential of traditional "single set" cutter layouts with the life extending features of a "plural set" cutter layout. The result is a bit that runs up to 20 percent faster than conventional PDC bits with minimum bit wear.

        Diamond PDC bits work across an extended range of weight on bit, penetrating quickly even at low bit weights in softer rock. When formations firm up, the bits can take added weight with a smooth torque response and maintain higher than competitive rates of penetration. The technology is a departure from traditional plural set bits that require higher weights to drill even in soft rock, and are generally durable, but slow, even in harder rock. Traditional plural set bits also can produce an erratic torque response when taking additional weight.





This innovative design allows operators to recognize drilling efficiencies through
Increased rates of penetration.
Enhanced Stability.
Optimum product durability.

Company Information

        Hebei Ranking Bit Manufacture Co.,Ltd is mainly engaged in the development of various series of bits,development,production and sales.

        Ranking company has developed and mass-produced products 3 inches to 26 inches series tci tricone bit,steel tooth tricone bit,various types of PDC bits,cone bit and production and processing assembly 0.6m to 3m large diameter hole opener,pdc hole opener,tci hole opener,steel tooth hole opener.Widely used in the oil,natural gas,hydrology,address,ore drilling engineering,product marketing the country and 20 countries and regions in the world.                  Ranking various rock bits,to ensure full compliance with all the terms and standard of American Petroleum Institute API specification,design,manufacturing and production and to ensure full compliance with the API specification requirements and content.
